Spesifikasi VORTEX 4 BASIC
Mixer Magnetic

Description

Vortex 4 BASIC

Vortex Mixer

Compact, universal small shaker suitable for shaking tasks with small vessels and microtiter plates

- Wide range of attachments

- Attachment detection- Digital timer with countdown function

- Continuous or touch operation (with standard attachment)

- Two operating modes:

   Mode A (safe mode with attachment detection) the maximum speed of 3,000 rpm is only reached with the standard attachment in touch mode. When using other attachments the speed is limited to 1,300 rpm.

   Mode B (without attachment detection) a speed of 3,000 rpm is possible with all attachments.

- Stable in all speed ranges

- Sturdy zinc die cast casing

Technical data:

- Shaker diameter : 4.5mm

- Motor rating input : 10W

- Motor rating output : 8W

- Current consumption : 800mA

- DC Voltage : 24V=

- Permissible ON time : 100%

- Power input : 20W

- Speed max. : 3000rpm

- Permissible shaking weight (incl. Attachment) : 0.5kg

- Weight : 3kg

- Width : 176mm

- Depth : 190mm

- Time setting max. : 999min

- Time setting min. : 1/60min

- Speed min (adjustable) : 200rpm

- Height : 63mm

- Frequency : 50/60Hz

- Voltage : 100 - 240V

- Operating mode : timer and continuous operation

- Protection class according to DIN EN 60529 : IP 21

- Touch function : yes

- Shaking table lock : no

- Type of movement : orbital

- Analog output : no

- Timer : yes

- Working with microtiter plates : yes

- Number of microtiter plates : 1

- Permissible ambient temperature max. : 40°C

- Permissible relative humidity : 80%

- Permissible ambient temperature min. : 5°C

- Speed min. : 0rpm

- Speed display : scale

- Timer display : 7 segment LED

- RS 232 interface : no
