Spesifikasi Fluke TP38 Slim
Alat Ukur Kuat Arus
Fluke T6-1000 Electrical Tester Features
- FieldSense technology for AC voltage, current and frequency measurement without making electrical contact to live voltage
- Simultaneous voltage and current display – shows all power supply measurements at a glance for efficient troubleshooting
- 1 to 1000V AC or DC (T6-1000)
- 0.1 to 200A AC
- True-RMS voltage and current
- Resistance 1 Ω to 100 kΩ
- Frequency measurement 45 Hz to 66 Hz
- Works with wires up to AWG 4/0 (120 mm2) with a 17.8 mm jaw opening
- HOLD button temporarily freezes the reading for easy viewing
- Easy to read display with backlight
- Accepts optional Fluke TPAK Magnetic Meter Hanger for convenient operation
- Standard two-year warranty; extendable to 4 years through product registration within 45 days of purchase
Fluke T6-1000 Electrical Tester Specifications
- Model Number: T6-1000
- Calibration: 1-year calibration cycle
- Dimensions: 61.1 x 259.3 x 43.8 mm
- Jaw opening: 17.8 mm
- Weight: 0.78 lb
- Temperature Operating -10 °C to +50 °C (14 °F to 122 °F)
- Storage -30 °C to +60 °C (-22 °F to +140 °F)
- Altitude Operating 2,000 m (6,562 feet)
- Storage 10,000 m (32,808 feet)
- Relative Humidity:
- a) 0% to 90%, 5 °C to 30 °C (41 °F to 86 °F)
- b) 0% to 75%, 30°C to 40 °C (86 °F to 104 °F)
- c) 0% to 45%, 40°C to 50 °C (104 °F to 122 °F)
- Battery Type and Life: 2 x AA (IEC LR6); 360 hours continuous, typical; 200 hours using FieldSense
- Temperature coefficient:
- 0.1 x (specified accuracy) / °C for <18°C or >28 °C
- 0.1 x (specified accuracy) / °C for <18°C or >28 °C
- Safety: IEC/EN 61010-1: Pollution Degree 2
- Electromagnetic Environment: IEC/EN 61326-1: Portable
- Price: $225
- Warranty: 2 years (4 years with registration)
